Lapping Machine
The Lapping Machine is a high-precision surface finishing machine designed to achieve exceptional flatness (within microns) and fine surface finish on a variety of engineering components. The large-diameter cast iron lapping plate rotates at variable speeds, driven by a variable frequency drive, while the conditioning rings keep the abrasive slurry evenly distributed across the plate surface. Adjustable lapping pressure allows the operator to control material removal rates, making the machine suitable for everything from rough lapping to ultra-fine finishing. Essential for seal faces, valve components, gauge blocks, and aerospace parts.
Key Specifications
- Lapping Plate Diameter
- Customizable (300mm to 1200mm)
- Plate Material
- Close-Grained Cast Iron
- Drive
- Variable Frequency Drive (VFD)
- Speed Range
- 10 to 100 RPM (adjustable)
- Flatness Achievable
- Within 1-2 microns
- Power Supply
- 415V / 3 Phase / 50 Hz
Features
- Achieves flatness within 1-2 microns
- Variable speed VFD-controlled lapping plate
- Adjustable lapping pressure via pneumatic/mechanical loading
- Automatic slurry distribution system
- Timer-controlled operation with cycle counter
- Available in single-plate and double-sided configurations
Applications
- Mechanical Seal Face Lapping
- Valve Seat Finishing
- Gauge Block Calibration
- Aerospace & Defense Components
- Fuel Injection Part Finishing
